Lasser cutting.

Laser cutting is a thermal cutting process where the cut is made using an amplified light beam – laser. A high-power laser is able to achieve high-quality results for metal cutting. Lasers can be used for any metalwork, including industrial applications.

It is more precise and less energy-consuming than plasma cutting but is more limited when it comes to cutting thick materials.

Grupo Doco’s laser cutting service offers CO2 and fibre lasers. While both use concentrated laser beams, the beam generation process uses different mechanisms. Both technologies have certain advantages, making them useful in certain situations.

Laser cutting allows great flexibility, accuracy and top quality. It can cut very complex shapes.

State of the art automated laser cutters need little manpower. Combining their autonomous nature to their swiftness, Grupo Doco’s online laser cutting platform enables keeping your project costs low.

The accuracy tolerance for positioning is +/- 0.1 mm. Thermal effects on the material are small, therefore it is possible to cut small holes with a minimum diameter of 1/2 the material thickness as well as holes that can be threaded after cutting without requiring additional machining. The cutting line width it is smaller than 0.5 mm for most materials.

Grupo Doco’s manufacturing network offers lasers that can cut a number of materials. These include carbon steel, stainless steel, high-strength steels as well as non-ferrous materials like aluminium, brass, copper and titanium. For metal plates thicker than 20 mm, see more about our plasma cutting capabilities. Aluminium cutting has its own rules.

Laser technology has an edge over other cutting methods when it comes to certain qualities. All those can work for your cause if you are aware of them.

The main advantages of laser cutting:

Great flexibility – One sheet may have 100 different cuts without having to change tools. Also, it is possible to cut all kinds of intricate shapes.

Precision – Accuracy of+/- 0.1 mm for laser cut parts gives the possibility to really cater to your most demanding needs. This kind of precision also ensures high quality.

Repeatability – +/- 0.05 mm ensures close to identical details.

Speed – Laser cutters are known for their speed, especially when cutting thin metal sheets.

Saves money – The machines are getting more energy efficient. Shuttle tables reduce the need for handling which means less need for manual labour. Smaller manufacturing costs result in lower total costs for the buyer.

Saving time – Laser cutting is automated. Therefore, it is the machinery that reads the drawings. The drawings only need to include cutting lines. This saves a lot of time in the drawing-room.
